When installing Windows 7 through USB drive on new skylake system, you may receive the following error message,
'A required CD/DVD drive device driver is missing. If you have a driver floppy disk, CD, DVD, or USB flash drive, please insert it now. '
In such case, the installation can't continue. The problem is caused by a missing USB 3.0 driver in the Windows 7 installation package. The Windows 7 installation program doesn't recognize the new USB 3.0 port, hence we need patch the driver to the installation package. Please follow the steps,
Power off your AMD USB 3.0 Host Controller device. Disconnect the device from your computer. Reconnect the device and power it on. Double click the driver download to extract it. If a language option is given, select your language. Follow the directions on the installation program screen. Reboot your computer. 1) Windows 7 doesn't Support USB 3.0 when installing. Now without doing some fancy work on slipstreaming the drives which can be a pain 2) ALL of Ryzen and Intel 7th Gen and up do NOT support anything but Windows 10 (Yea you can wiggle in there and install it but you will NOT get any updates and there are no official windows 7 drivers so. Download AMD USB 3.0 Host Controller chipset drivers or install DriverPack Solution software for driver update. Windows XP, 7, 8, 8.1, 10 (x64, x86). Download the latest AMD USB 3 0 Host Controller driver for your computer's operating system. All downloads available on this website have been scanned by the latest anti-virus software and are guaranteed to be virus and malware-free. Edit: To be clear, even if you do not get the USB 3.0 and 3.1 drivers into the Win 7 Install.wim, by copying the install.wim onto a windows 10 USB stick in the sources folder (overwrite the Win 10 install.wim file), you can use the USB 3.0 and 3.1 peripherals to install Win 7 SP1 on the drive.
Step 1 - Create Windows 7 bootable USB drive from Windows 7 ISO file
Usb 3.0 Peripherals
You can find the detail procedure here. Let's assume the USB drive has the drive letter H: after you have created Windows 7 bootable USB drive successfully.
Step 2 - Download and unpack Intel(R) USB 3.0 eXtensible Host Controller Driver
You may download it from https://downloadcenter.intel.com/product/65855 .
There are two zip files for the driver. Just unzip them to a local folder, with different sub folder for each file, for example, C:USB3driver1, and C:USB3driver2.
Step 3 - Run PowerISO DISM Tool
Run PowerISO, and select the menu, 'Tools --> DISM Tool'. On Windows vista or above Windows operating systems, you will need confirm UAC dialog to continue.
Step 4 - Mount WIM file in the USB drive
In 'DISM Tool' dialog, select 'Mount / Unmount' page, and click the button 'Mount..'.
The 'Mount image' dialog will popup. Click 'Browse' button to select the boot WIM file in USB drive, for example, H:sourcesboot.wim.
Select the image index from the list, usually, it should be '2: Microsoft Windows Setup (x64)' for 64-bit Windows 7 ISO file, or '2: Microsoft Windows Setup (x86)' for 32-bit Windows 7 ISO file.
Create an empty folder, for example, C:mount, and select it for the mount path.
What Is Usb 3.0?
Click 'Mount' to mount the image in WIM file to the specified path.
You should get the message, 'The operation completed successfully' after the image has been successfully mounted to the specified the path. Click 'OK' to close the message box.
Step 5 - Patch drivers into the image
Select 'Driver Servicing' page, and select 'C:mount' from the mounted directories list.
Click 'Add driver..' button.
The 'Add driver' dialog will popup. Select 'C:usb3' for the driver folder, and check the option, 'Recurse - Query all subfolders for drives'.
Click 'OK' to add the drivers to the image.
You should see the message like below after the operation completes. Click 'OK' to close the message box.
Step 6 - Unmount WIM file
Select 'Mount / Unmount' page, and select 'C:mount' from the images list.
Click 'Unmount' button.
The 'Unmount image' dialog will popup. Make sure the unmount path is 'C:mount', and check the option, 'Commit - Save the changes when unmounting image file'. Click 'Unmount' to unmount the image.
You should get the message below after the operation completed successfully.
You might receive the error message below when unmounting the image,
The directory could not be completely unmounted. This is usually due to applications that still have files opened within the mount directory. Close these files and unmount again to complete the unmount process.
In such case, please close all programs which might open the files in mounted directory, especially close all Explorer Windows, and then try unmounting the image again. Apple iphone software for windows.
Step 7 - Patch drivers to install.wim
Repeat step 4 to step 6 to patch drives to install.wim. Usually install.wim can be found in the sources folder, for example, the full path name looks like H:sourcesinstall.wim.
If there are several images in install.wim, you need select the correct image to patch. If you are not sure which image should be patched, you can patch all images in install.wim (repeat step 4 to step 6 for each image in the wim file).
Step 8 - Install Windows 7 from the patched USB drive
Amd Usb 3.0 Driver Windows 7 64
You have patched the USB 3.0 driver to Windows 7 installation package successfully. You can now use it to install Windows 7 from the USB 3.0 port, which is present in most new skylake computers. Please also make sure that the BIOS is properly configured for booting from the USB device.
